n8n vs Automatisch vs Node-RED: Workflow Automation (2026)

TL;DR

n8n is the workflow automation platform — visual builder, 400+ integrations, code nodes (JavaScript/Python), webhooks, self-hosted or cloud, the most popular open-source Zapier alternative. Automatisch is the open-source Zapier alternative — simple trigger-action flows, self-hosted, privacy-focused, growing integration list. Node-RED is the flow-based programming tool — IoT-focused, visual wiring, MQTT/HTTP/WebSocket nodes, function nodes, dashboard, runs on Raspberry Pi to cloud. In 2026: n8n for business workflow automation, Automatisch for simple Zapier-like flows, Node-RED for IoT and data pipelines.

Key Takeaways

• n8n: 50K+ GitHub stars — 400+ integrations, code nodes, AI workflows
• Automatisch: 6K+ GitHub stars — Zapier alternative, simple flows, privacy-first
• Node-RED: 20K+ GitHub stars — IoT, flow programming, MQTT, dashboard
• n8n has the largest integration ecosystem and most advanced workflow features
• Automatisch provides the simplest Zapier-like experience for self-hosting
• Node-RED excels at IoT, hardware, and real-time data processing

---

n8n

n8n — workflow automation platform:

Installation

# Docker:
docker run -d \
  --name n8n \
  -p 5678:5678 \
  -v n8n-data:/home/node/.n8n \
  n8nio/n8n

# Docker Compose (production):

# docker-compose.yml
version: "3.8"

services:
  n8n:
    image: n8nio/n8n:latest
    ports:
      - "5678:5678"
    environment:
      - N8N_HOST=n8n.example.com
      - N8N_PORT=5678
      - N8N_PROTOCOL=https
      - WEBHOOK_URL=https://n8n.example.com/
      - DB_TYPE=postgresdb
      - DB_POSTGRESDB_HOST=postgres
      - DB_POSTGRESDB_PORT=5432
      - DB_POSTGRESDB_DATABASE=n8n
      - DB_POSTGRESDB_USER=n8n
      - DB_POSTGRESDB_PASSWORD=secret
      - N8N_ENCRYPTION_KEY=your-encryption-key
    volumes:
      - n8n-data:/home/node/.n8n
    depends_on:
      - postgres

  postgres:
    image: postgres:16-alpine
    environment:
      POSTGRES_USER: n8n
      POSTGRES_PASSWORD: secret
      POSTGRES_DB: n8n
    volumes:
      - postgres-data:/var/lib/postgresql/data

volumes:
  n8n-data:
  postgres-data:

Workflow via API

// n8n REST API — create and manage workflows:
const N8N_URL = "https://n8n.example.com"
const N8N_API_KEY = process.env.N8N_API_KEY!

const headers = {
  "X-N8N-API-KEY": N8N_API_KEY,
  "Content-Type": "application/json",
}

// Create workflow:
const workflow = await fetch(`${N8N_URL}/api/v1/workflows`, {
  method: "POST",
  headers,
  body: JSON.stringify({
    name: "Package Download Monitor",
    nodes: [
      {
        parameters: {
          rule: { interval: [{ field: "hours", hoursInterval: 6 }] },
        },
        name: "Schedule Trigger",
        type: "n8n-nodes-base.scheduleTrigger",
        position: [250, 300],
      },
      {
        parameters: {
          url: "https://api.npmjs.org/downloads/point/last-week/react",
          method: "GET",
        },
        name: "Fetch Downloads",
        type: "n8n-nodes-base.httpRequest",
        position: [450, 300],
      },
      {
        parameters: {
          conditions: {
            number: [{
              value1: "={{ $json.downloads }}",
              operation: "larger",
              value2: 25000000,
            }],
          },
        },
        name: "Check Threshold",
        type: "n8n-nodes-base.if",
        position: [650, 300],
      },
      {
        parameters: {
          channel: "#alerts",
          text: "🔥 React downloads exceeded 25M: {{ $json.downloads }}",
        },
        name: "Slack Alert",
        type: "n8n-nodes-base.slack",
        position: [850, 200],
      },
    ],
    connections: {
      "Schedule Trigger": {
        main: [[{ node: "Fetch Downloads", type: "main", index: 0 }]],
      },
      "Fetch Downloads": {
        main: [[{ node: "Check Threshold", type: "main", index: 0 }]],
      },
      "Check Threshold": {
        main: [
          [{ node: "Slack Alert", type: "main", index: 0 }],
          [],
        ],
      },
    },
    active: true,
  }),
}).then((r) => r.json())

// Execute workflow manually:
await fetch(`${N8N_URL}/api/v1/workflows/${workflow.id}/execute`, {
  method: "POST",
  headers,
})

// List executions:
const executions = await fetch(
  `${N8N_URL}/api/v1/executions?workflowId=${workflow.id}&limit=10`,
  { headers }
).then((r) => r.json())

Code node (JavaScript)

// n8n Code Node — runs JavaScript/Python:

// Process incoming data:
const items = $input.all()

const processed = items.map((item) => {
  const { name, downloads, version } = item.json

  return {
    json: {
      name,
      downloads,
      version,
      downloads_formatted: new Intl.NumberFormat().format(downloads),
      trend: downloads > 1000000 ? "popular" : "growing",
      updated_at: new Date().toISOString(),
    },
  }
})

return processed

// Access environment variables:
// const apiKey = $env.MY_API_KEY

// Access previous node data:
// const webhookData = $('Webhook').first().json

// HTTP request in code:
// const response = await $http.request({
//   method: 'GET',
//   url: 'https://api.example.com/data',
//   headers: { Authorization: 'Bearer token' },
// })

Webhook workflow

// n8n Webhook — receive external events:

// Webhook node listens at:
// POST https://n8n.example.com/webhook/package-updates

// Example: GitHub webhook → process → notify:
// 1. Webhook Trigger (receives GitHub push event)
// 2. Code Node (extract package info)
// 3. HTTP Request (fetch npm stats)
// 4. IF Node (check if downloads changed significantly)
// 5. Slack/Email notification

// Call n8n webhook from your app:
await fetch("https://n8n.example.com/webhook/package-updates", {
  method: "POST",
  headers: { "Content-Type": "application/json" },
  body: JSON.stringify({
    package: "react",
    event: "version_released",
    version: "19.1.0",
    timestamp: new Date().toISOString(),
  }),
})

---

Automatisch

Automatisch — open-source Zapier:

Installation

# Docker Compose:
git clone https://github.com/automatisch/automatisch.git
cd automatisch
cp .env.example .env
docker compose up -d

# docker-compose.yml
version: "3.8"

services:
  automatisch-main:
    image: automatischio/automatisch:latest
    ports:
      - "3000:3000"
    environment:
      - APP_ENV=production
      - APP_SECRET_KEY=your-secret-key
      - POSTGRES_HOST=postgres
      - POSTGRES_PORT=5432
      - POSTGRES_DATABASE=automatisch
      - POSTGRES_USERNAME=automatisch
      - POSTGRES_PASSWORD=secret
      - REDIS_HOST=redis
      - ENCRYPTION_KEY=your-encryption-key
    depends_on:
      - postgres
      - redis

  automatisch-worker:
    image: automatischio/automatisch:latest
    command: npm run worker
    environment:
      - APP_ENV=production
      - APP_SECRET_KEY=your-secret-key
      - POSTGRES_HOST=postgres
      - POSTGRES_DATABASE=automatisch
      - POSTGRES_USERNAME=automatisch
      - POSTGRES_PASSWORD=secret
      - REDIS_HOST=redis
      - ENCRYPTION_KEY=your-encryption-key
    depends_on:
      - postgres
      - redis

  postgres:
    image: postgres:16-alpine
    environment:
      POSTGRES_USER: automatisch
      POSTGRES_PASSWORD: secret
      POSTGRES_DB: automatisch
    volumes:
      - postgres-data:/var/lib/postgresql/data

  redis:
    image: redis:7-alpine
    volumes:
      - redis-data:/data

volumes:
  postgres-data:
  redis-data:

Flow configuration

// Automatisch flows follow a trigger → action pattern:

// Example flow: New GitHub issue → Slack notification
// Configuration via the web UI:

// Trigger: GitHub — New Issue
// Config:
//   Repository: myorg/my-project
//   Event: issues.opened

// Action: Slack — Send Message
// Config:
//   Channel: #github-issues
//   Message: "New issue: {{trigger.issue.title}}\n{{trigger.issue.html_url}}"

// Example flow: Webhook → Database → Email
// Trigger: Webhook — catch incoming data
// Action 1: PostgreSQL — Insert row
//   Table: events
//   Columns: { type: "{{trigger.body.type}}", data: "{{trigger.body}}" }
// Action 2: Email — Send notification
//   To: team@example.com
//   Subject: "New event: {{trigger.body.type}}"

API

// Automatisch GraphQL API:
const AUTOMATISCH_URL = "https://automatisch.example.com"
const AUTOMATISCH_TOKEN = process.env.AUTOMATISCH_TOKEN!

const headers = {
  Authorization: `Bearer ${AUTOMATISCH_TOKEN}`,
  "Content-Type": "application/json",
}

// List flows:
const { data } = await fetch(`${AUTOMATISCH_URL}/graphql`, {
  method: "POST",
  headers,
  body: JSON.stringify({
    query: `
      query GetFlows {
        getFlows {
          edges {
            node {
              id
              name
              active
              status
              steps {
                id
                type
                appKey
                status
              }
              createdAt
              updatedAt
            }
          }
        }
      }
    `,
  }),
}).then((r) => r.json())

// Get execution history:
const executions = await fetch(`${AUTOMATISCH_URL}/graphql`, {
  method: "POST",
  headers,
  body: JSON.stringify({
    query: `
      query GetExecutions($flowId: String!) {
        getExecutions(flowId: $flowId) {
          edges {
            node {
              id
              status
              createdAt
              executionSteps {
                id
                status
                dataOut
              }
            }
          }
        }
      }
    `,
    variables: { flowId: "flow-id" },
  }),
}).then((r) => r.json())

Supported integrations

// Automatisch currently supports:

// Communication:
// - Slack, Discord, Microsoft Teams, Twilio

// Developer:
// - GitHub, GitLab, Webhooks

// Productivity:
// - Google Sheets, Google Calendar, Google Drive
// - Notion, Todoist

// CRM/Marketing:
// - HubSpot, Mailchimp, SendGrid

// Database:
// - PostgreSQL, MySQL, MongoDB

// Other:
// - HTTP Request, RSS, Schedule/Cron
// - SMTP Email, Typeform, Stripe

// Custom apps:
// Community app development follows a structured pattern:
// - Trigger definitions
// - Action definitions
// - Authentication configuration
// - Data mapping

---

Node-RED

Node-RED — flow-based programming:

Installation

# npm (global):
npm install -g node-red
node-red

# Docker:
docker run -d \
  --name node-red \
  -p 1880:1880 \
  -v node-red-data:/data \
  nodered/node-red:latest

# docker-compose.yml
version: "3.8"

services:
  node-red:
    image: nodered/node-red:latest
    ports:
      - "1880:1880"
    volumes:
      - node-red-data:/data
    environment:
      - TZ=America/Los_Angeles
    restart: unless-stopped

volumes:
  node-red-data:

Flow definitions (JSON)

[
  {
    "id": "webhook-trigger",
    "type": "http in",
    "url": "/api/package-update",
    "method": "post",
    "name": "Package Update Webhook"
  },
  {
    "id": "parse-payload",
    "type": "function",
    "name": "Parse Package Data",
    "func": "const { name, version, downloads } = msg.payload;\nmsg.package = { name, version, downloads };\nmsg.payload = { name, version, downloads_formatted: downloads.toLocaleString() };\nreturn msg;",
    "wires": [["check-threshold"]]
  },
  {
    "id": "check-threshold",
    "type": "switch",
    "name": "Check Downloads",
    "property": "package.downloads",
    "rules": [
      { "t": "gt", "v": "1000000", "vt": "num" },
      { "t": "else" }
    ],
    "wires": [["slack-notify"], ["log-only"]]
  },
  {
    "id": "slack-notify",
    "type": "http request",
    "method": "POST",
    "url": "https://hooks.slack.com/services/xxx",
    "name": "Slack Notification"
  }
]

Function nodes (JavaScript)

// Node-RED Function Node — full JavaScript:

// Process incoming messages:
const payload = msg.payload

// Fetch npm data:
const response = await fetch(
  `https://api.npmjs.org/downloads/point/last-week/${payload.name}`
)
const data = await response.json()

msg.payload = {
  name: payload.name,
  weekly_downloads: data.downloads,
  trend: data.downloads > payload.previous_downloads ? "up" : "down",
  change_pct: (
    ((data.downloads - payload.previous_downloads) / payload.previous_downloads) *
    100
  ).toFixed(1),
  checked_at: new Date().toISOString(),
}

// Set topic for MQTT:
msg.topic = `packages/${payload.name}/stats`

return msg

// Node-RED Function Node — multiple outputs:
const package_data = msg.payload

if (package_data.downloads > 10000000) {
  // Output 1: High traffic packages
  return [{ payload: { ...package_data, tier: "high" } }, null, null]
} else if (package_data.downloads > 1000000) {
  // Output 2: Medium traffic
  return [null, { payload: { ...package_data, tier: "medium" } }, null]
} else {
  // Output 3: Low traffic
  return [null, null, { payload: { ...package_data, tier: "low" } }]
}

HTTP API and MQTT

// Node-RED HTTP endpoint flow:

// HTTP In → Function → HTTP Response
// Creates: GET /api/packages

// Function node:
const packages = flow.get("packages") || []

msg.payload = {
  count: packages.length,
  packages: packages.slice(0, 20),
  updated_at: flow.get("last_update"),
}
msg.headers = { "Content-Type": "application/json" }

return msg

// MQTT integration:
// MQTT In node subscribes to: packages/+/updates
// Function node processes the message
// MQTT Out node publishes to: packages/processed

// Dashboard (node-red-dashboard):
// Gauge, Chart, Text, Button, Form nodes
// Auto-generates a web dashboard at /ui

Custom nodes

// Create custom Node-RED node:

// package-checker.js
module.exports = function (RED) {
  function PackageCheckerNode(config) {
    RED.nodes.createNode(this, config)
    const node = this

    node.on("input", async function (msg) {
      const packageName = config.package || msg.payload.name

      try {
        const response = await fetch(
          `https://registry.npmjs.org/${packageName}`
        )
        const data = await response.json()

        msg.payload = {
          name: data.name,
          version: data["dist-tags"].latest,
          description: data.description,
          license: data.license,
        }

        node.status({ fill: "green", shape: "dot", text: `${data.name}@${data["dist-tags"].latest}` })
        node.send(msg)
      } catch (error) {
        node.status({ fill: "red", shape: "ring", text: error.message })
        node.error(error.message, msg)
      }
    })
  }

  RED.nodes.registerType("package-checker", PackageCheckerNode)
}

// package-checker.html
// <script type="text/javascript">
//   RED.nodes.registerType('package-checker', {
//     category: 'function',
//     color: '#a6bbcf',
//     defaults: { name: { value: "" }, package: { value: "" } },
//     inputs: 1,
//     outputs: 1,
//     label: function() { return this.name || "package-checker" }
//   })
// </script>

---

Feature Comparison

Feature	n8n	Automatisch	Node-RED
License	Fair-code (SEL)	AGPL v3	Apache 2.0
Interface	Visual workflow	Visual flow	Visual wiring
Integrations	400+	30+	4000+ (community)
Code execution	✅ (JS/Python)	❌	✅ (JS)
Webhooks	✅	✅	✅
Scheduling	✅ (cron)	✅ (cron)	✅ (inject node)
Error handling	✅ (retry, fallback)	Basic	✅ (catch nodes)
Sub-workflows	✅	❌	✅ (subflows)
AI nodes	✅ (LangChain, OpenAI)	❌	Via community
Version control	✅	❌	✅ (projects)
Multi-user	✅	✅	Via admin
MQTT	Via node	❌	✅ (native)
Dashboard	❌	❌	✅ (built-in)
IoT support	Limited	❌	✅ (core strength)
Self-hosted	✅	✅	✅
Cloud hosted	✅	❌	❌ (FlowFuse)
Resource usage	Medium	Low	Low

---

When to Use Each

Use n8n if:

• Want the most integrations and advanced workflow automation
• Need code nodes (JavaScript/Python) for custom logic
• Building business automation (CRM, marketing, ops workflows)
• Want AI-powered workflows with LangChain/OpenAI nodes

Use Automatisch if:

• Want the simplest Zapier-like self-hosted experience
• Need basic trigger-action flows without code
• Prefer privacy-focused, fully open-source automation
• Building straightforward integrations between SaaS tools

Use Node-RED if:

• Building IoT, hardware, or real-time data processing flows
• Need MQTT, serial, or hardware protocol support
• Want a visual dashboard for monitoring data streams
• Building data transformation pipelines with custom nodes

---

Methodology

GitHub stars as of March 2026. Feature comparison based on n8n v1.x, Automatisch v0.x, and Node-RED v4.x.

Compare automation tools and developer platforms on PkgPulse →
