Scalar vs Redoc vs Swagger UI: API Documentation UIs (2026)

·PkgPulse Team
javascripttypescriptapideveloper-tools

TL;DR

Scalar is the modern API documentation UI — beautiful design, built-in API client for testing, dark mode, OpenAPI 3.1 support, customizable theming. Redoc is the three-panel API docs renderer — clean three-column layout, OpenAPI 3.x, search, code samples, used by major API providers. Swagger UI is the original OpenAPI renderer — interactive "Try it out" feature, the most widely used, powers SwaggerHub, official OpenAPI tooling. In 2026: Scalar for modern beautiful docs with API client, Redoc for clean reference documentation, Swagger UI for interactive API testing.

Key Takeaways

  • Scalar: ~500K weekly downloads — modern UI, API client, dark mode, OpenAPI 3.1
  • Redoc: ~1M weekly downloads — three-panel layout, search, code samples
  • Swagger UI: ~3M weekly downloads — "Try it out", most widely used, official tooling
  • All three render OpenAPI/Swagger specs into interactive documentation
  • Scalar has the most modern design and built-in API testing
  • Swagger UI's "Try it out" makes live API requests from the docs

Scalar

Scalar — modern API documentation:

Basic setup

<!-- CDN (quickest start): -->
<script
  id="api-reference"
  data-url="https://api.pkgpulse.com/openapi.json"
></script>
<script src="https://cdn.jsdelivr.net/npm/@scalar/api-reference"></script>

Express integration

import express from "express"
import { apiReference } from "@scalar/express-api-reference"

const app = express()

app.use(
  "/docs",
  apiReference({
    spec: {
      url: "/openapi.json",
    },
    theme: "purple",
  })
)

app.get("/openapi.json", (req, res) => {
  res.json(openapiSpec)
})

// → http://localhost:3000/docs

Hono integration

import { Hono } from "hono"
import { apiReference } from "@scalar/hono-api-reference"

const app = new Hono()

app.get(
  "/docs",
  apiReference({
    spec: { url: "/openapi.json" },
    pageTitle: "PkgPulse API",
    theme: "kepler",
  })
)

Configuration

import { apiReference } from "@scalar/express-api-reference"

app.use("/docs", apiReference({
  spec: { url: "/openapi.json" },

  // Theme:
  theme: "purple",    // purple, saturn, kepler, mars, moon, default
  darkMode: true,

  // Customization:
  layout: "modern",   // modern, classic
  showSidebar: true,

  // Authentication:
  authentication: {
    preferredSecurityScheme: "bearerAuth",
    apiKey: {
      token: "default-api-key",
    },
  },

  // Custom CSS:
  customCss: `
    .scalar-app { --scalar-color-1: #3b82f6; }
  `,

  // Metadata:
  metaData: {
    title: "PkgPulse API Reference",
    description: "Compare npm packages",
  },
}))

Features

Scalar highlights:

  ✅ Built-in API client (test endpoints without leaving docs)
  ✅ Dark mode (toggleable)
  ✅ Modern, clean design
  ✅ OpenAPI 3.0 and 3.1 support
  ✅ Search across endpoints
  ✅ Request/response examples
  ✅ Multiple language code samples
  ✅ Authentication support
  ✅ Customizable themes
  ✅ Framework integrations (Express, Hono, Fastify, Next.js)

Redoc

Redoc — three-panel docs:

Basic setup

<!-- CDN: -->
<script src="https://cdn.redoc.ly/redoc/latest/bundles/redoc.standalone.js"></script>
<div id="redoc-container"></div>
<script>
  Redoc.init("https://api.pkgpulse.com/openapi.json", {
    theme: {
      colors: { primary: { main: "#3b82f6" } },
    },
  }, document.getElementById("redoc-container"))
</script>

React component

import { RedocStandalone } from "redoc"

function APIReference() {
  return (
    <RedocStandalone
      specUrl="https://api.pkgpulse.com/openapi.json"
      options={{
        theme: {
          colors: {
            primary: { main: "#3b82f6" },
          },
          typography: {
            fontFamily: "Inter, sans-serif",
          },
          sidebar: {
            backgroundColor: "#1a1a1a",
            textColor: "#ffffff",
          },
        },
        hideDownloadButton: false,
        expandResponses: "200,201",
        requiredPropsFirst: true,
        sortPropsAlphabetically: true,
        pathInMiddlePanel: true,
      }}
    />
  )
}

Express middleware

import express from "express"
import redoc from "redoc-express"

const app = express()

app.get("/docs", redoc({
  title: "PkgPulse API",
  specUrl: "/openapi.json",
  redocOptions: {
    theme: {
      colors: { primary: { main: "#3b82f6" } },
    },
  },
}))

Configuration

const redocOptions = {
  // Layout:
  hideDownloadButton: false,
  hideHostname: false,
  hideLoading: false,
  hideSchemaPattern: false,
  hideSingleRequestSampleTab: false,

  // Content:
  expandResponses: "200,201",  // Auto-expand these status codes
  requiredPropsFirst: true,
  sortPropsAlphabetically: true,
  pathInMiddlePanel: true,
  jsonSampleExpandLevel: 2,

  // Sidebar:
  menuToggle: true,
  nativeScrollbars: false,

  // Code samples:
  generateCodeSamples: {
    languages: [
      { lang: "curl" },
      { lang: "Node.js" },
      { lang: "Python" },
    ],
  },

  // Theme:
  theme: {
    colors: {
      primary: { main: "#3b82f6" },
      success: { main: "#10b981" },
      error: { main: "#ef4444" },
    },
    typography: {
      fontFamily: "Inter, sans-serif",
      fontSize: "15px",
      headings: { fontFamily: "Inter, sans-serif" },
    },
    sidebar: {
      width: "260px",
      backgroundColor: "#1a1a1a",
    },
    rightPanel: {
      backgroundColor: "#0f172a",
    },
  },
}

Swagger UI

Swagger UI — interactive API docs:

Basic setup

<!-- CDN: -->
<link rel="stylesheet" href="https://cdn.jsdelivr.net/npm/swagger-ui-dist/swagger-ui.css" />
<div id="swagger-ui"></div>
<script src="https://cdn.jsdelivr.net/npm/swagger-ui-dist/swagger-ui-bundle.js"></script>
<script>
  SwaggerUIBundle({
    url: "https://api.pkgpulse.com/openapi.json",
    dom_id: "#swagger-ui",
    presets: [
      SwaggerUIBundle.presets.apis,
      SwaggerUIBundle.SwaggerUIStandalonePreset,
    ],
  })
</script>

Express integration

import express from "express"
import swaggerUi from "swagger-ui-express"
import openapiSpec from "./openapi.json"

const app = express()

app.use("/docs", swaggerUi.serve, swaggerUi.setup(openapiSpec, {
  customSiteTitle: "PkgPulse API",
  customCss: ".swagger-ui .topbar { display: none }",
  swaggerOptions: {
    persistAuthorization: true,
    displayRequestDuration: true,
    filter: true,
    tryItOutEnabled: true,
  },
}))

// → http://localhost:3000/docs

"Try it out" feature

Swagger UI's killer feature — execute API requests from the docs:

1. Open endpoint: GET /api/packages
2. Click "Try it out"
3. Fill in parameters: name = "react"
4. Click "Execute"
5. See real response:

   curl -X GET "https://api.pkgpulse.com/api/packages?name=react"

   Response:
   200 OK
   {
     "name": "react",
     "downloads": 25000000,
     "version": "19.0.0"
   }

This makes API testing and exploration interactive.

Configuration

import swaggerUi from "swagger-ui-express"

const options = {
  // UI options:
  customSiteTitle: "PkgPulse API",
  customfavIcon: "/favicon.ico",
  customCss: `
    .swagger-ui .topbar { display: none }
    .swagger-ui .info .title { color: #3b82f6 }
  `,

  // Swagger options:
  swaggerOptions: {
    persistAuthorization: true,
    displayRequestDuration: true,
    docExpansion: "list",      // "list", "full", "none"
    filter: true,              // Search filter
    tryItOutEnabled: true,     // Enable "Try it out" by default
    defaultModelsExpandDepth: 2,
    defaultModelExpandDepth: 2,

    // OAuth2:
    oauth2RedirectUrl: "https://api.pkgpulse.com/docs/oauth2-redirect",
    initOAuth: {
      clientId: "your-client-id",
      scopes: ["read", "write"],
    },
  },
}

app.use("/docs", swaggerUi.serve, swaggerUi.setup(spec, options))

Feature Comparison

FeatureScalarRedocSwagger UI
DesignModern, beautifulThree-panelClassic
Dark mode✅ (built-in)✅ (theme)❌ (custom CSS)
"Try it out"✅ (API client)❌ (paid addon)✅
Search✅✅✅ (filter)
Code samples✅✅❌
OpenAPI 3.1✅✅✅
OpenAPI 3.0✅✅✅
Swagger 2.0❌✅✅
React component✅✅✅
Express middleware✅✅✅
Hono/Fastify✅❌✅ (Fastify)
Custom theming✅✅ (deep)✅ (CSS)
Self-hosted✅✅✅
Weekly downloads~500K~1M~3M

When to Use Each

Use Scalar if:

  • Want the most modern, beautiful API documentation
  • Need a built-in API client for testing endpoints
  • Building with Hono, Express, or Fastify
  • Want dark mode and customizable themes out of the box

Use Redoc if:

  • Need clean three-panel reference documentation
  • Want auto-generated code samples in multiple languages
  • Building public-facing API docs for developer portals
  • Need deep theming and branding customization

Use Swagger UI if:

  • Need interactive "Try it out" API testing
  • Want the most widely recognized API docs format
  • Need OAuth2 flow support in the docs
  • Have Swagger 2.0 specs (legacy support)

Methodology

Download data from npm registry (weekly average, February 2026). Feature comparison based on @scalar/api-reference v1.x, redoc v2.x, and swagger-ui-express v5.x.
